FS16i/18i/21i - TB/MA/MB Additional Manual Page 88

Additional Manual
FANUC Series 16i/18i/21i-MA/MB/TB TOOL MANAGEMENT FUNCTION A-78614EN
2002.08.08 Edition 04
88
#7 #6 #5 #4 #3 #2 #1 #0
13203 TCN SWC NM4 NM3 NM2 NM1
[Data type] Bit
NMx The x-th magazine
0 : can be searched by CNC.
1 : can not be searched by CNC.
TCN Tool life count starts by
0 : M06 or Tool count restart M code.
(Tool life count does not start by only T code)
1 : T code. (Tool life count does not start by M06)
NOTE
- This parameter is only for i-series model B.
13220 Valid tool number of tool management data
[Data type] Word
[Valid data range] 0, 1 to 64 (additional option : 1 to 240, 1 to 1000)
Sets the valid tool number of tool management data.
