FANUC Series 16i/18i/21i-MA/MB/TB TOOL MANAGEMENT FUNCTION A-78614EN
2002.08.08 Edition 04
92
Alarm and message
Number Message Description
154 NOT USING TOOL IN
LIFE GROUP
Even though the tool management
number is not allocated to the spindle
position, H99 or D99 was commanded.
Please modify the program.
5312 ILLEGAL COMMAND IN
G10 L75/76
The mistake is found in the command
format among G11 from G10
L75/L76/L77, or the instruction value
exceeds the range of data. Please
modify the program.
5316 TOOL TYPE NUMBER
NOT FOUND
The tool with specified tool type
number is not found.
Please modify the program or register
the tool.
5317 ALL TOOL LIFE IS OVER The life of all tools with specified tool
type number has been reached.
Change the tools.
