FS16i/18i/21i - TB/MA/MB Additional Manual Page 95

Additional Manual
FANUC Series 16i/18i/21i-MA/MB/TB TOOL MANAGEMENT FUNCTION A-78614EN
2002.08.08 Edition 04
95
12.1 Exchange of tool management data number in the magazine
management table
[Description]
This function exchanges tool management data number in a pair of pots of specified magazine.
[Input data structure]
0 (Function code)
329
2 (Completion code)
-
4
(Data length)
8
6
(Data number)
-
8
(Data attribute)
-
10
(Data number2)
-
12
(Detail completion code)
-
14
Magazine No.1 (2byte)
16
Pot No.1 (2byte)
18
Magazine No.2 (2byte)
20
Pot No.2 (2byte)
When the magazine number is set to 11-14(1-4
th
spindle position) or 21-24(1-4
th
waiting position), the pot
number may be dummy number.
It is necessary for specifying the 2
nd
or 3
rd
spindle/wait position at the multipath system to specify the path
number by the place of 100. For example, the magazine number 213 means the 3
rd
spindle position at the
2
nd
path. Especially, the 1
st
spindle position can be specified without the third of hundreds (The magazine
number 22 and 122 indicates the same magazine).
