FS16i/18i/21i - TB/MA/MB Additional Manual Page 77

Additional Manual
FANUC Series 16i/18i/21i-MA/MB/TB TOOL MANAGEMENT FUNCTION A-78614EN
2002.08.08 Edition 04
77
7.8 Notices
• Total pot number of all magazines is as shown in the table below.
Maximum of the pot number
Tool management function
64
Tool management function 240 pairs
240
Tool management function 1000 pairs
1,000
The number of pots of each magazine is secured from the first magazine.
example) When the maximum pot number is 64.
Parameter setting Effective pot number
First magazine
30 30
Second magazine
20 20
Third magazine
20 14
Fourth magazine
20 0
• When the parameter No.13220, 13222-13251 is rewritten, the tool
management data number of all magazines is initialized by 0. The
purpose of this is to prevent contradiction being caused in the
correspondence of the tool management data and the magazine
management table.
example)When the tool management data number 60 is set to the pot
number 1 of the first magazine, if the value of parameter 13220 is
changed to the value 30, the tool management data number 60
which stored in the pot doesn’t exist.
• When the data is edited, the tool management data number blinks. This
data is removed from the search object of the next tool. And, in this
time, this data can't be edited through the window of PMC and
FOCAS1. This state continues until the end of tool management data
edit mode.
• When the names of the customizing data and the tool life state data are
set by using G10, please switching to other NC screens once. The
change of the name setting doesn’t become effective until this
operation is done.
