SERIES 16/18/160/180/MODEL C Maintenance manual Page 158

Maintenance manual

Page of 516

/ 516

2. HARDWARE

B–62755EN/01

144

⋅ LED display of CAP–II function

j: OFF, J: ON, Ll: Blink, Z: Don’t care

No. LED display NC status

1 STATUS JJJJ

ALARM jjj

Startup status immediately after power is

turned on

2 STATUS ZZjJ

ALARM jjj

Waiting for each procesor in the system to set

its ID

3 STATUS ZZJj

ALARM jjj

Waiting for each processor in the system to

complete startup

4 STATUS ZZjj

ALARM jjj

The CAP II function startup has been com-

pleted and the system is now in normal opera-

tion

⋅ LED display when an error occurs

j: OFF, J: ON, Ll: Blink, Z: Don’t care

No. LED display NC status

1 STATUS ZZLL

ALARM jjj

NMI from another board (STATUS LEDs 3 and

4 are flashing simultaneously). Check other

boards’ LED display.

2 STATUS ZZjL

ALARM jjj

A CAP II sub–memory parity error occurred.

Initialize the sub–memory.

3 STATUS ZZLj

ALARM jjj

A bus error occurred (incorrect memory ac-

cess). Replace the option 3 board.

4 STATUS ZZLl

ALARM jjj

A ROM parity error occurred (STATUS LEDs 3

and 4 are flashing alternately). Replace the

CAP II ROM module.

⋅ Alarm LED display j:OFF, J:ON

LED display Description Cause and required action

ALARM jjJ An I/O link error occurred. Check the link devices and

cables.

ALARM jJj A parity error occurred in the

SRAM for CAP–II

The SRAM module for CAP–II

may be out of order

ALARM jJJ A parity error occurred in the

DRAM for PMC

The option 3 board or DRAM

module for PMC may have

failed.

ALARM Jjj A parity error occurred in the

DRAM for CAP–II

The DRAM module for CAP–II

may have failed

ALARM JjJ A parity error occurred in the

DRAM for PMC

The option 3 board or DRAM

module for PMC may have

failed.

ALARM JJj The CPU for PMC is not started Check whether the main board

has been activated normally

ALARM JJJ The operation of the PMC

module is abnormal

The PMC module may have

failed
