SERIES 16/18/160/180/MODEL C Maintenance manual Page 300

Maintenance manual

Page of 516

/ 516

7. AC SPINDLE (ANALOG INTERFACE)

B–62755EN/01

286

Name Signal contents Remarks

DA2 Analog speed command

voltage (SVC)

0X+10V, Rated speed at 10V

PA Pulse generator output

A–phase

90° advance by PB at CW rotation

p–p

=0.36–0.5V

PB Pulse generator output

B–phase

90° delay by PA at CW rotation

p–p

=0.36–0.5V

RA A–phase standard voltage +2. 5V DC "0. 2V

RB B–phase standard voltage +2. 5V DC "0. 2V

PAP A phase pulse waveform Duty 50% (ON/ OFF ratio)

PBP B phase pulse waveform Duty 50% (ON/ OFF ratio)

TSA Speed feedback signal At maximum rated max. rotation

"10V(CW:+,CCW:–)

TS2 Low–speed detection signal At CCW (forward rotation)

22.5rpm , –1.4V"0.3V

TS3 Speed pulse F/V converison

signal

At CCW (forward rotation)

6000 rpm , –4.65 to –6.15V

VCMD Speed command voltage 0X"10V, (CCW:+, CW: – )

TSAF CCW rotation speed detection

signal

At CCW (forward rotation)

6000 rpm , 0. 82V "82mv

TSAR CW rotation speed

detection signal

At CW (backward rotation)

6000 rpm , 0. 82V "82mv

ER Error voltage –4.2X+4.8V

CLK1 Clock signal 2. 5MHz , duty 50%

SLIP Slip pulse

VDC DC link voltage signal Voltage 1/100 of DC link voltage

SDC Control power DC link

voltage

Voltage 1/100 of control power DC link

voltage

ADIN A/D converter input signal

IU U–phase current detection

signal

IV V–phase current detection sig-

nal

IW W–phase current detection

signal

+24V +24V DC voltage About 23V "4%

+15V +15V DC voltage +15V"4%

+5V +5V DC voltage +5V"4%

–15V –15V DC voltage –15V"4%

*RGHLD Regenerative stop signal

7.2.2

Models 6S to 26S

(Amp. specification:

A06B–6059–H2xx)

Model 6SX12S 15SX22S 26S

Current 33.3 A/V 66.6 A/V 83.3 A/V

value
