SERIES 16/18/160/180/MODEL C Maintenance manual Page 491

Maintenance manual
APPENDIX
B–62755EN/01
D. BOOT SYSTEM
479
The boot system organizes files in flash ROM into two main groups :
system files and user files. These two file types have the following
characteristics :
CNC and servo control software provided by FANUC
PMC sequence program (ladder), P–CODE macro program, and other
user–created files
When OPT2 board or LCB (loader control board) is mounted on the CNC,
we have to access to flash ROM or SRAM that mounted on additional
board. So, the boot system displays BOOT SLOT CONFIGURATION
screen that to select a access board.
BOOT SLOT CONFIGURATION 60M1–02
NO. BOARD F–ROM SRAM
0. MAIN 4MB 1.0MB
1. OPT2 6MB 1.0MB
2. OPT3 128KB
3. LCB 512KB
*** MESSAGE ***
SELECT SLOT AND HIT SELECT KEY.
[ SELECT ][ YES ][ NO ][ UP ][ DOWN ]
(1)
(2)
(3)
(1): Screen title.
(2): Flash memory size and SRAM size of each board.
(3): Message
Press the [ UP ] or [DOWN] soft key to move the cursor, and select board
to press the [SELECT] soft key.
Memory card slot
The memory card slot on the loader control board (LCB) is provided specifically for the ladder
edit card for the loader. When a memory card is to be used in the boot system, insert the card
into the slot provided on the main board.
D.1.2
System Files and User
Files
D System files
D User files
D.1.3
Boot Slot
Configuration Screen
D Screen configuration
D Operation
