9. TROUBLESHOOTING (SERIAL INTERFACE SPINDLE)

B–62755EN/01

394

Item Cause of trouble Check procedure Remedy

1 Defective PCB

Check AC in

ut voltage

Replace PCB.

Abnormal power sup-

ply voltage

Check

in ut

voltage

See (5) above.

Item Cause of trouble Check procedure Remedy

Incorrect setting of

parameter for number

of speed feedback

pulses (No. 6511)

Check if number of speed

feedback pulses matches

parameter setting.

Set correct value in

parameter.

NOTE

See Chapter 6.

Item Cause of trouble Check procedure Remedy

AC power supply volt-

age 10% higher than

rated voltage.

Check power supply

voltage.

Incorrect setting of

toggle switch for volt-

age switching.

Check power supply

voltage.

Change setting from 200V

to 230V.

Item Cause of trouble Check procedure Remedy

Cooling fan is defec-

tive.

Check if fan is rotating. Replace fan.

Overload operation. Check load by using a

load meter.

Re-examine the cutting

condition.

Dusty and dirty. Clean using compressed

air or vacuum cleaner.

This alarm indicates abnormally low AC power voltage (–15% or less).

This alarm may be generated even during momentary power failures.

Item Cause of trouble Check procedure Remedy

High power imped-

ance.

Examine AC power specifi-

cation.

2 PCB is defective. Replace PCB.

Defective transistor

module (TM1).

Replace transistor mod-

ule.

Item Cause of trouble Check procedure Remedy

Output terminals or

internal circuit of mo-

tor is shorted.

Check connections.

Transistor module is

defective.

Check the transistor

module.

Replace transistor module.

3 PCB is defective. Replace PCB.

AL–05 Control power

supply fuse blown

AL–07 Excessive speed

(Detection by

digital value)

AL–08 High input voltage

AL–09 Heat sink is

overheated

AL–10 Input power

voltage drops

AL–11 Overvoltage of DC

link circuit

(Regenerative

circuit is

faulty…Regenerati

on failure)

AL–12 Overcurrent flows

to DC link circuit
