8. TROUBLESHOOTING

B–62755EN/01

378

920: Watch dog alarm or RAM parity in servo control module

has occurred in servo control module on the main CPU board

922: Above alarm has occurred in servo control module on the option 3

board

The timer used to monitor the operation of CPU is called the watch dog

timer. The CPU resets timer time every time a constant time has passed.

When an error occurs in CPU or peripheral device, timer is not reset but

the alarm is informed.

Refer to alarm 910 to 915

The servo module includes servo RAM, watch dog timer circuit, etc.

Defectiveness of hardware, abnormality or malfunctioning of detection

circuit or the like is considered. Therefore, replace servo module on the

main CPU board for alarm 920 and 921; replace servo module on the

option 2 board for alarm 922 and 923.

Servo module

Main

CPU

ROM

RAM

(A20B–2902–0061, A20B–2902–0070)

CPU or peripheral circuits may be faulty. Replace the main CPU board.

Software may not work properly due to failure of FROM module. Change

FROM module.

DC output voltage of power supply unit may be faulty. Replace the power

supply unit.

8.33

ALARM 920, 922

(WATCH DOG OR

RAM PARITY)

points

D Watch dog timer alarm

D RAM parity error

Causes and Remedies

D Servo control module is

faulty

D Main CPU board is faulty

D CNC control software

ROM module is faulty

D Power supply unit is

faulty
