2. HARDWARE

B–62755EN/01

166

Name RemarksSpecification

8.4″ separate–type LCD unit Color A02B–0200–C051

Separate–type MDI unit

(small size)

TC A02B–0120–C121#TA

(

sma

)

A02B–0120–C121#TAR Conforming to

safety standards

MC A02B–0120–C121#MA

A02B–0120–C121#MAR

Separate–type MDI unit

(standard)

TC A02B–0120–C122#TA

(

A02B–0120–C122#TAR

MC A02B–0120–C122#MA

A02B–0120–C122#MAR

9.5″ separate–type LCD unit Color A02B–0200–C113

Separate–type MDI unit

(For 9.5″ LCD, standard key,

landcape type)

TC A02B–0200–C125#TAR Conforming to

safety standards

cape

ype

)

A02B–0200–C125#TAS Conforming to

safety standards

symbolic keys

MC A02B–0200–C125#MAR Conforming to

safety standards

A02B–0200–C125#MAS Conforming to

safety standards

symbolic keys

Separate–type MDI unit (For

9.5″ LCD, standard key, por-

trait type)

TC A02B–0200–C126#TAR Conforming to

safety standards

ype

)

A02B–0200–C126#TAS Conforming to

safety standards

symbolic keys

MC A02B–0200–C126#MAR Conforming to

safety standards

A02B–0200–C126#MAS Conforming to

safety standards

symbolic keys
