SERIES 16/18/160/180/MODEL C Maintenance manual Page 467

Maintenance manual

Page of 516

/ 516

APPENDIX

B–62755EN/01

B. ALARM LIST

455

Message CountermeasureContents

Er–16 Differential mode command (DEFMDA) is entered when

differential speed function is disabled by parameter set-

ting (No.6500#5=1).

Check parameter setting and control input signal.

Er–17 Parameter setting (No.6511#0,1,2) for speed detector is

incorrect. (Specified speed detector is not present.)

Check parameter setting.

Er–18 Spindle orientation command of position coder type is

entered when use of position coder signal is disabled by

parameter setting( No.6501#2=0).

Check parameter setting and control input signal.

Er–19 Although the command for orienting the magnetic sensor

system was entered, another mode was issued.

Do not issue another mode while the orientation

command is executed. Before issuing another

mode, cancel the orientation command.

Er–20 Both the slave mode and the high–resolution magnetic

pulse coder were enabled.

These two settings are incompatible. Check the

parameter settings.

Er–21 The slave mode command (SLV=1) was entered under

position control (servo mode, orientation,etc.).

Enter the slave mode command in the normal op-

eration mode.

Er–22 The position control command (servo mode, orienta-

tion,etc.) was entered in the slave operation mode

(SLV=1).

Enter the position control command in the normal

operation mode.

Er–23 A slave mode command was entered when the slave

mode is disabled.

Enable the slave mode.

Er–24 To perform continuous indexing in the mode for orienting

the position coder system, incremental opera-

tion(INCMD=1) was first performed, then the absolute

position command (INCMD=0) was entered.

Check the control input signal (INCMD). To

execute the absolute position command continu-

ously, be sure to perform orientation with the abso-

lute position command first.

Contact sig-

nal of *ESP

Between ESP1 and ESP2 of spindle control printed cir-

cuit board

Contact is open : emergency stop

Contact is closed : general operation

Alarm

No.

Meaning Description Remedy

“A”

display

Program ROM abnormality

(not installed)

Detects that control program is not started (due to

program ROM not installed, etc.)

Install normal program

ROM

AL–01 Motor

overheat

Detects motor speed exceeding specified speed ex-

cessively.

Check load status.

Cool motor then reset

alarm.

AL–02 Excessive speed deviation Detects motor speed exceeding specified speed ex-

cessively.

Check load status.

Reset alarm.

AL–03 DC link section fuse blown Detects that fuse F4 in DC link section is blown

(models 30S and 40S).

Check power transistors,

and so forth.

Replace fuse.

AL–04 Input fuse blown.

Input power open phase.

Detects blown fuse (F1 to F3), open phase or mo-

mentary failure of power (models 30S and 40S).

Replace fuse.

Check open phase and

power supply regenerative

circuit operation.

AL–05 Control power supply fuse

blown

Detects that control power supply fuse AF2 or AF3

is blown (models 30S and 40S).

Check for control power

supply short circuit .

Replace fuse.

AL–07 Excessive speed Detects that motor rotation has exceeded 115% of its

rated speed.

Reset alarm.

Alarms (Serial spindle)
