9.SPINDLE SPEED FUNCTION NC FUNCTIONS B-63782EN/01

- 120 -

9.6 SPINDLE SPEED CLAMP (G92)

With the following command, a maximum spindle speed can be set:

G92 S_; (where S_: Maximum spindle speed in min

-1

)

A set maximum spindle speed is output to the PMC as a 16-bit binary

code. On the PMC, the spindle speed needs to be clamped according to

the output maximum spindle speed.

Whether the S command specified in a block in which G92 is specified

is to be regarded as a command for specifying a maximum spindle

speed can be chosen by parameter setting.

9.7 ACTUAL SPINDLE SPEED OUTPUT

An actual spindle speed calculated using a feedback signal from the

position coder attached to the spindle is output to the PMC as a 16-bit

binary code. With a serial spindle, a spindle speed can also be

calculated from the spindle motor speed monitor data.
