25.16 CLEARING THE SCREEN

If the same character is displayed at the same position on the screen for

a long time, the life of the LCD will be shortened.

To prevent this from occurring, the CNC screen can be cleared. There

are two ways to do this: using the screen clear function, executed by

pressing a key, and automatic screen clear function, which

automatically clears the screen if there has been no key activity for the

time set for a parameter.

25.17 PERIODIC MAINTENANCE SCREEN

The periodic maintenance screen provides a guideline indicating when

consumables that require periodic replacement (such as the battery for

control unit backup and the LCD unit back-light) are to be replaced and

checked if their service lives are set in advance.
