B-63782EN/01 APPENDIX B.LIST OF FUNCTION AND TAPE FORMAT

- 409 -

B LIST OF FUNCTION AND TAPE FORMAT

The symbols in the list represent the following.

IP _ : X _ Y _ Z _ A _

As seen above, the format consists of a combination of arbitrary axis

addresses among X, Y, Z, A, B, C, U, V, and W

x : First basic axis (X usually)

y : Second basic axis (Y usually)

z : Third basic axis (Z usually)

a : One of arbitrary addressed

b : One of arbitrary addressed

Xp : X axis or its parallel axis

Yp : Y axis or its parallel axis

Zp : Z axis or its parallel axis

Functions Illustration Tape format

Positioning (G00) G00 IP_ ;

Linear interpolation (G01) G01 IP_ F_;

Circular interpolation

(G02, G03)

Helical interpolation

(G02, G03)

(x, y)

(xyz)

Start

point

(In case of X-Y plane)

G02

G03

p_ Yp_

I_ J_

α_F_ ;

G17

G02

G03

p_ Zp_

I_ K_

α_F_ ;

G18

G02

G03

Yp_ Zp_

J_ K_

α_F_ ;

G19

α : Any axis other than circular interpolation axes.

Start point

G02

G03

p_ Yp_

I_ J_

F_ ;

G17

G02

G03

p_ Zp_

I_ K_

F_ ;

G18

G02

G03

Yp_ Zp_

J_ K_

F_ ;

G19

Start point

(x, y)

G03

(x, y)

G02

Start point
