16.COORDINATE SYSTEM CONVERSION FUNCTION NC FUNCTIONS B-63782EN/01

- 230 -

In three-dimensional coordinate conversion mode, the following two

types of manual interruption are supported:

(1) Operation in a workpiece coordinate system (with three-

dimensional coordinate conversion not applied)

(2) Operation in a program coordinate system (with three-dimensional

coordinate conversion applied)

- Three-dimensional rigid tapping

Rigid tapping in three-dimensional coordinate conversion mode

enables three-dimensional rigid tapping.

- Coordinate system during three-dimensional coordinate conversion

Format

G68 Xp x

Yp y

Zp z

I i

J j

K k

Rα

αα

α ; Starting three-dimensional coordinate conversion

G68 Xp x

Yp y

Zp z

I i

J j

K k

Rβ

ββ

β ; Second three-dimensional coordinate conversion

: Three-dimensional coordinate conversion mode

G69 ; Canceling three-dimensional coordinate conversion

Symbol

Xp, Yp, Zp : Center of rotation (absolute coordinates) on the X, Y, and Z axis or parallel axes

I, J, K : Direction of the axis of rotation

R : Angular displacement

The above command places the machine in three-dimensional

coordinate conversion mode. The following coordinate systems are

used in three-dimensional coordinate conversion mode.

Coordinate system definition

Coordinate system X, Y, Z :

Original workpiece coordinate system

Coordinate system X', Y', Z' :

Coordinate system after the first coordinate conversion

N1 specifies the rotation center, rotation center axis

direction, and angular displacement of the first rotation. As

a result of the first rotation, coordinate system X', Y', and Z'

is produced which has its center shifted by (x1,y1,z1) with

respect to the original workpiece coordinate system, and is

rotated about (i1,j1,k1) by α.

Coordinate system X", Y", Z" : Program coordinate system

N2 specifies the rotation center, rotation center axis

direction, and angular displacement of the second rotation.

As a result of the second rotation, coordinate system X", Y",

and Z" is produced which has its center shifted by (x2,y2,z2)

with respect to coordinate system X', Y', Z', and is rotated

about (i2,j2,k2) by β

Note that Xp, Yp, Zp, I, J, K, and R in N2 are the coordinates

and angle in the coordinate system produced by conversion

by N1.

Programmed values Xp, Yp, and Zp in N3 are regarded as being the

coordinates in program coordinate system X", Y", and Z".
