9.SPINDLE SPEED FUNCTION NC FUNCTIONS B-63782EN/01

- 124 -

G26 places the system in spindle speed fluctuation detection enabled

mode and sets the P, Q, R, and I command addresses in parameters Nos.

5071, 5702, 5721, and 5722. The parameter numbers corresponding to

the command addresses are as follows:

Command address Parameter number

Q 5701

R 5702

I 5721

P 5722

If any of the P, Q, R, and I command addresses is omitted, spindle

speed fluctuation detection is performed with the value set in the

corresponding parameter (No. 5071, 5702, 5721, or 5722).

- Disabling spindle speed fluctuation detection

G25;

G25 places the system in spindle speed fluctuation detection disabled

mode.

Specifying G25 does not change the settings of parameters Nos. 5071,

5702, 5721, and 5722.

If G26 (bit 4 of parameter No. 2409) is "0," the system enters spindle

speed fluctuation detection disabled mode (G25) when the power is

turned on or a reset is performed.
