Servo Amplifier Unit Alpha Series Descriptions Page 20

Descriptions
2. CONFIGURATION
B–65192EN/02
4
Table 2.1.1 (b) Applied motor
Applied motor group
AC Servo Motor
Group A α0.5/3000, α1/3000 ,α2/2000 ,α2/3000,
αE1/3000, αE2/3000
Group B αC3/2000, αC6/2000, αC12/2000, αE3/2000,
αE6/2000
Group C α2.5/3000, α3/3000, α6/2000, α12/2000,
αC22/1500 α22/1500, αM3/3000, αL3/3000
Group D α6/3000, α12/3000, α22/2000, α30/1200,
αM6/3000, αM9/3000, αL6/3000, αL9/3000
Group E α22/3000, α30/2000, α30/3000, α40/2000,
α40/2000 (with fan) αL25/3000, αL50/2000
Group F α2.5/3000, α3/3000, α6/2000, α12/2000,
αL3/3000, αM3/3000
Group G α6/3000, αM6/3000
The SVUC is used to enable maintenance of, or is used as a replacement
for, the C series amplifier.
Table 2.1.2 Replacing the C Series Amplifier with the SVUC
Axis
Replacing the C series amplifier with the SVUC Name
A06B–6066–H002 ³ A06B–6090–H002 SVUC1–4
A06B–6066–H003 ³ A06B–6090–H003 SVUC1–12
1 A06B–6066–H004 ³ A06B–6090–H004 SVUC1–40
A06B–6066–H006 ³ A06B–6090–H006 SVUC1–80
A06B–6066–H008 ³ A06B–6090–H008 SVUC1–130
A06B–6066–H222 ³ A06B–6090–H222 SVUC2–4/4
A06B–6066–H223 ³ A06B–6090–H223 SVUC2–4/12
A06B–6066–H224 ³ A06B–6090–H224 SVUC2–4/40
A06B–6066–H233 ³ A06B–6090–H233 SVUC2–12/12
2 A06B–6066–H234 ³ A06B–6090–H234 SVUC2–12/40
A06B–6066–H236 ³ A06B–6090–H236 SVUC2–12/80
A06B–6066–H244 ³ A06B–6090–H244 SVUC2–40/40
A06B–6066–H246 ³ A06B–6090–H246 SVUC2–40/80
A06B–6066–H266 ³ A06B–6090–H266 SVUC2–80/80
The interchangeable C series amplifier and SVUC have identical model
names (last nibble) in the drawing numbers. The middle nibbles of the
drawing numbers, however, are different: 6066 for the C series amplifier
and 6090 for the SVUC.
C series amplifier
A06B–6066
–Hjjj
SVUC
A06B–6090
–Hjjj
Same model name as that
of the C series amplifier
2.1.2
SVUC Types
