9. CONNECTION
B–65192EN/02
56
9
CONNECTION
This servo amplifier unit has two types of NC interface. Cable connection
varies with the interface type used. Before starting to connect, check the
model of the NC unit and interface type.
Interface type NC
TYPE A Series 0–C, Series 15–A, Series 15–B, Series 16–A, Series
16–B, Series 18–A, Series 21–TA, Power Mate–D, Power
Mate–F
TYPE B Series 20–A, Series 21–TB, Series 21–GA, Series 16–B,
Series 18–B, Power Mate–H
CAUTION
The Series 16–B can have both types of interface. Check
the interface type with the arranged NC.
SVU: This unit has been designed to comply with VDE0160. A
machine that is configured using this unit would easily be able
to gain approval to display the CE marking (machinery
directive). A requirement for obtaining approval is an external
MCC which trips in the event of an emergency stop.
Sample connections without external MCC: 9.2.1 (1), (2)
Sample connections with external MCC: 9.2.1 (3), (4)
SVUC: This unit does not comply with VDE0160. A machine
configured using the unit will not be able to gain approval to
display the CE marking.
Sample general connections: 9.2.2 (1), (2)
