Servo Amplifier Unit Alpha Series Descriptions Page 83

Descriptions
B–65192EN/02
9. CONNECTION
67
(3) For connection to Series 16–B, Series 18–B, Series 20, Series 21–TB,
Series 21–GA, or Power Mate–H (TYPE B I/F)
NC
*PWMA (*ALM1)
( 3)
Series 16–B
Series 18–B
0V
( 4)
Series 20
Series 21–TB
*PWMC (*ALM2)
( 5)
Series 21–GA
Power Mate H
0V
( 6)
( 7)
*PWME (*ALM4)
( 7)
( 8)
0V
( 8)
(13)
*ENBL (*ALM8)
(13)
(14)
0V
(14)
( 1)
IR
( 1)
( 2)
GDR
( 2)
(11)
IS
(11)
(12)
GDS
(12)
(19)
0V
(19)
(20)
0V
(20)
( 9)
*DRDY
( 9)
(10)
*MCON
(10)
(15)
PD
(15)
(16)
*PD
(16)
(17)
PREQ
(17)
(18)
*PREQ
(18)
Connector: PCR–E20FA etc.
Connector
Connector: PCR–E20FA etc.
Connector name
JS1B: L axis (first axis)
JS2B: M axis (second axis)
( 3)
( 4)
( 5)
( 6)
SVU
SVUC
Wire material: 0.08mm twisted pair totally shielded cable (10 pairs)
CAUTION
Cables designed for the TYPE B interface can also be used
with the TYPE A interface. Cables designed for the TYPE
A interface, however, cannot be used with the TYPE B
interface.
