Servo Amplifier Unit Alpha Series Descriptions Page 32

Descriptions
3. SPECIFICATION
B–65192EN/02
16
(3) Switch 2 setting
The settings of the SVU and SVUC differ.
Switch 2 setting
ON SVUC
OFF SVU
If the setting is incorrect, the VRDY OFF alarm may occur.
(4) Switch 3 and 4 setting
The setting varies depending on the regenerative discharge resistance
used.
If the setting is incorrect, the regenerative discharge control circuit
failure alarm (DCSW) cannot be detected correctly.
(a) SVU1 – 12, 20
SW3 SW4 Regenerative Discharge Resistor
ON ON Built–in (20W)
ON OFF Separate A06B–6066–H510 (100W),
A06B–6089–H510 (100W)
OFF OFF Separate A06B–6066–H500 (200W),
A06B–6089–H500 (200W)
(b) SVUC1 – 4, 12
SW3 SW4 Regenerative Discharge Resistor
ON ON Built–in (20W)
(c) SVU1 – 40, 80 , SVU2 – j/j
SVUC1 – 40, 80, SVUC2 – j/j
SW3 SW4 Regenerative Discharge Resistor
ON ON Built–in (100W)
ON OFF Separate A06B–6066–H500 (200W),
A06B–6089–H500 (200W)
OFF OFF Separate A06B–6066–H713 (800W),
A06B–6066–H714 (1200W)
A06B–6089–H713 (800W)
A06B–6089–H714 (1200W)
(d) SVU1 –130, SVUC1–130
SW3 SW4 Regenerative Discharge Resistor
ON ON Built–in (400W)
ON OFF Separate A06B–6066–H711 (800W),
A06B–6089–H711 (800W)
OFF OFF Separate A06B–6066–H712 (1200W),
A06B–6089–H712 (1200W)
