C.4 SERVO CHECK BOARD
(1) General
The servo check board receives the digital value used
for contol inside the digital servo as numerical data
and converts it to an analog form.
(2) Servo check board specifications
Specification Name
A06B-6057-H602 Servo check board (with a cable having a provision to
prevent incorrect insertion)
A02B-0236-K822 Servo adaptor board (for i series )
(3) Connection the servo check board
When connecting the check board, always keep the NC
switched off. obtain a correct Keep on strapping on the
5 MHz side of clock pin S1 on the check board.
Series 16i, 18i, 21i, Power Mate Model Di, Hi
Adaptor board
TEST 1
CN 0
TEST 0
NC
MAIN CPU
Connector
CA54
Adaptor
cable
Preventing
reverse
insertion
cable
Servo check
board third and
fourth axes
Servo check
board first and
second axes
Servo check
board seventh
and eighth axes
Servo check
board fifth and
sixth axes
TEST 3TEST 2
