Servo Motors Beta Series Maintenance manual Page 7

Maintenance manual
B–65235EN/02
SAFETY PRECAUTIONS (FANUC AC SERVO MOTOR series)
6
1
WARNING
WARNING
F Be safely dressed when handling a motor.
Wear safety shoes or gloves when handling a motor as you may get hurt on any edge or protrusion
on it or electric shocks.
F Use a crane or lift to move a motor from one place to another.
Motors are heavy. When moving them, use a crane or lift as required. (For the weight of motors,
refer to their respective specification manuals.)
When moving a motor using a crane or lift, use a hanging bolt if the motor has a corresponding
tapped hole, or textile rope if it has no tapped hole. If a motor is attached with a machine or any
other heavy stuff, do not use a hanging bolt to move the motor as the hanging bolt and/or motor
may get broken. When moving a motor, be careful not to apply excessive force to its windings
as the windings may break and/or their insulation may deteriorate.
F Do not touch a motor with a wet hand.
A failure to observe this caution is vary dangerous because you may get electric shocks.
F Before starting to connect a motor to electric wires, make sure they are
isolated from an electric power source.
A failure to observe this caution is vary dangerous because you may get electric shocks.
F Do not bring any dangerous stuff near a motor.
Motors are connected to a power line, and may get hot. If a flammable is placed near a motor,
it may be ignited, catch fire, or explode.
F Be sure to ground a motor frame.
To avoid electric shocks, be sure to connect the grounding terminal in the terminal box to the
grounding terminal of the machine.
F Do not ground a motor power wire terminal or short–circuit it to another
power wire terminal.
A failure to observe this caution may cause electric shocks or a burned wiring.
: Some motors require a special connection such as a winding changeover. Refer to their
respective motor specification manuals for details.
