3.TROUBLESHOOTING AND
RECOVERY PROCEDURES TROUBLESHOOTING AND RECOVERY
B-65235EN/02
- 66 -
(1) For a full-closed Series 0-C system, make sure that the
phase C signal connection is correct, or when the
system is not a Series 0-C, go to (2).
(2) If there is a large backlash; or if the number of position
feedback pulses divided by the motor one -rotation
signal is equal to or less than 640, and a soft ware
disconnected alarm is detected when it should
not,change the alarm level.
#7 #6 #5 #4 #3 #2 #1 #0
2003 8X03 TGAL
TGAL(#1)=1 (the software disconnected alarm level is changed.)
2064 8X64 Soft ware disconnected alarm level(TGALMLV)
Standard value: 4 The setting is increased by 4.
(3) If the alarm is a separate detector hardware
disconnected alarm, ckeck the specification and wiring
of the separate detector.
3.3.4
Motor Overheat Alarm
(1) Check whether the motor has overheated;
If the motor is overheated, use it less frequently.
(2) When the motor is cooled enough, check whether an
overheat alarm occurs.
If it occurs, the thermostat is defective.
If not, use the motor less frequently.
WARNING
It is dangerous to touch the motor by the hand or any other
part of you body.
