3. START-UP PROCEDURE START-UP PROCEDURE B-65235EN/02
- 34 -
3.2
CONNECTING THE POWER SUPPLY
3.2.1
Confirming the Line Voltage and Power Requirements
(1) Line voltage
Before connecting the power source to the machine,
check the voltage of the power source.
Item Specification
Input power Three-phase Voltage 200 to 240VAC
Allowable deviation voltage+10%, –15%
Note)
Frequency 50 Hz , 60 Hz ±2 Hz
Voltage deviation due to load (at maximum
output) shall be 7% or less.
Single-phase Voltage 220 to 240VAC
Allowable deviation voltage+10 %, 15 %
Note
)
Frequency 50 Hz , 60 Hz ±2 Hz
Voltage deviation due to load (at maximum
output) shall be 7% or less.
Control power voltage
24VDC ±10 %
NOTE
Allowable deviation voltage means deviation for a few
minutes, not continuous.
