3. START-UP PROCEDURE START-UP PROCEDURE B-65235EN/02
- 42 -
• Series 16, 18, 20, 21, Power Mate-D, F, H, I
#7 #6 #5 #4 #3 #2 #1 #0
1815 OPTX
↑
Must be specified for all NCs.
OPTX (#1) The separate position detector is :
1 : used
0 : Not used
• Series 0-C
#7 #6 #5 #4 #3 #2 #1 #0
0037 STP8 STP7 STP4 STPZ STPY STPX
STPX to 8 The separate position detector is :
1 : Used for the X-axis, Y-axis, Z-axis, fourth axis, seventh
axis, and eighth axis
0 : Not used for the X-axis, Y-axis, Z-axis, fourth axis,
seventh axis, and eighth axis
• Power Mate-E
#7 #6 #5 #4 #3 #2 #1 #0
1002 GRSL P FSE
GRSL(#7) The separate position detector is :
1 : Used
0 : Not used
PFSE(#3) Set GRSL,PFSE to same value.
10) Specify the reference counter. The reference
counter is used in making a return to the
reference position by a grid method. The value to
be specified in the number of pulses necessary for
the motor to make one turn, or the value obtained
by dividing the number by an integer.
α, β pulse coder, semi-closed(detection in 1 µm units)
Ball screw lead
Number of necessary
position pulses
Reference counter Grid width
10mm/rev 10000 pulse/rev 10000 10 mm
20 20000 20000 20
30 30000 30000 30
NOTE
For Series 16, 18, 20 and 21, setting this parameter causes
bit 3 of parameter No.2002 to be set to 1 automatically.
