C. FSSB APPENDIX B-65235EN/02
- 104 -
C.6 i SERIES INITIAL SETTING OF PARAMETER
C.6.1 Outline
In the system using FSSB, we have to set the following
parameters for the axis arrangement.
(Please set the parameters as usual except the following
ones)
l No.1023
l No.1905
l No.1910 to 1919
l No.1936, 1937
In order to these parameters, there are 3 ways as follows.
1. Manual setting 1
By setting the parameter in No.1023, the axis
arrangement is decided as the default setting. You do
not have to need to set the parameter No.1905, 1910 ~
1919, 1936, 1937. But There is a limitation of function
which you can use.
2. Automatic setting
By using FSSB setting screen, when you input the
amplifier and axis informations, CNC set the
parameter No.1905, 1910 to 1919, 1936, 1937
automatically.
3. Manual setting 2
Please input the parameter No.1905, 1910 to 1919,
1936, 1937 by hand after you understand the meaning
of each parameter well.
