Servo Motors Beta Series Maintenance manual Page 92

Maintenance manual
B-65235EN/02 APPENDIX B. MOTOR PARAMETER LIST
- 91 -
9041, 9046 series
Motor model 2-0SP/3 1-0SP 1-0SP/3
α 0.5 α E1/3 α E2/3 α E3/2 α E6/2
Motor specification 371 372 373 0113 0101 0102 0105 0106
Motor model
α C3 α C6 α C12 α 1/3 α 2/2 α 2/3 β 0.5 β 1/3 β 2/3 β 3/3 β 6/2
Motor
specification
0121 0126 0141 0371 0372 0373 0113 0031 0032 0033 0034
Motor type 7 8 9 61 46 62 13 35 36 33 34
Symbol Parameter No.
FS0-C
8 03 00001000 00001000 00001000 00001000 00000000 00001000 00001000 00001100 00001100 00001100 00001100
8 04 00000110 00000110 00000110 01000110 01000110 01000110 00000110 00000110 00000110 00000110 01000110
8 05 00000000 00000000 00000000 00000000 00000000 00000000 00000000 00000100 00000100 00000100 00000100
8 06 01000100 01000100 01000000 01000100 00000000 01000100 01000100 01000000 01000000 01000000 01000000
8 10 00000010 00000010 00000010 00000000 00000000 00000000 00000010 00000000 00000010 00000010 00000010
PK1 8 40 1600 1800 3000 390 1170 450 220 359 704 275 990
PK2 8 41 –5059 –6105 –9750 –1053 –2289 –900 –540 –1129 –2401 –1006 –3544
PK3 8 42 –2608 –2641 –2687 –2480 –2485 –2503 –2556 –2564 –2596 –2622 –2632
PK1V 8 43 107 127 251 111 91 128 9 102 62 144 144
PK2V 8 44 –955 –1140 –2245 –997 –812 –1146 –79 –916 –1111 –2587 –2587
PK3V 8 45 00 000000000
PK4V 8 46 –8235 –8235 –8235 –8235 –8235 –8235 –8235 –8235 –8235 –8235 –8235
POA1 8 47 3974 3329 1690 3806 4674 3311 –4789 4141 3415 1467 1467
BLCMP 8 48 000000 00000
RESERV 8 49 00 000000000
POK1 8 50 956 956 956 956 956 956 956 956 956 956 956
POK2 8 51 510 510 510 510 510 510 510 510 510 510 510
RESERV 8 52 3843 3844 3842 0 0 0 3844 0 3072 3840 3072
PPMAX 8 53 21 21 21 21 21 21 21 21 21 21 21
PDDP 8 54 1894 1894 1894 3787 3787 3787 1894 1894 1894 1894 3787
PHYST 8 55 319 319 319 319 319 319 319 319 319 319 319
EMFCMP 8 56 3046 4381 4000 2800 2147 2520 1200 2500 3300 3000 3200
PVPA 8 57 2100 1800 2400 2330 1864 2330 2000 2100 2700 3200 2000
PALPH 8 58 42 48 42 57 46 57 77 71 78 80 57
PPBAS 8 59 55 550555555
TQLIM 8 60 7282 7282 7282 7282 7282 7282 7282 7282 7282 7282 7282
EMFLMT 8 61 120 120 120 120 120 120 120 120 120 120 120
POVC1 8 62 32686 32637 32412 32623 32627 32519 32585 32617 32540 32456 32456
POVC2 8 63 1030 1636 4446 1811 1766 3112 2288 1884 2850 3897 3897
TGALMLV 8 64 444444 44444
POVCLMT 8 65 3056 4858 13245 5377 5245 9256 6797 5594 8474 11600 11600
PK2VAUX 8 66 0 0000000000
FILTER 8 67 00 000000000
FALPH 8 68 000000 00000
VFFLT 8 69 00000000000
ERBLM 8 70 00 000000000
PBLCT 8 71 00 000000000
RESERV 8 72 00 000000000
RESERV 8 73 00 000000000
AALPH 8 74 4000 4000 0 1680 0 2940 1000 0000
MODEL 8 75 0 0000000000
WKAC 8 76 00 000000000
OSCTPL 8 77 00 000000000
RESERV 8 78 00 000000000
RESERV 8 79 00 000000000
RESERV 8 80 00 000000000
RESERV 8 81 00 000000000
BLENDL 8 82 0 0000000000
MOFCTL 8 83 000000 00000
SDMR1 8 84 0 0000000000
SDMR2 8 85 0 0000000000
RTCURR 8 86 1286 1622 2678 1706 1685 2239 1918 1740 2142 2506 2506
TDPLD 8 87 00 000000000
MCNFB 8 88 0 0000000000
BLBSL 8 89 00 000000000
ROBSTL 8 90 0 0000000000
ACCSPL 8 91 000000 00000
ADFF1 8 92 00000000000
VMPK3V 8 93 00 0000012923 14203 12923 12923
BLCMP2 8 94 00000000000
AHDRTL 8 95 00 000000000
RADUSL 8 96 00 000000000
RESERV 8 97 00 000000000
DEPVPL 8 98 12800 17920 17920 50 0 0 5160 80 –2786 –1476 30
ONEPSL 8 99 400 400 400 400 400 400 400 400 400 400 400
