Servo Motors Beta Series Maintenance manual Page 45

Maintenance manual
3. START-UP PROCEDURE START-UP PROCEDURE B-65235EN/02
- 44 -
• Power Mate -E
#7 #6 #5 #4 #3 #2 #1 #0
21 APCX
APCX (#0)
1 : Performs absolute position as communication pulse
coder.
0 : Does not perform as absolute position pulse coder.
2. After making sure that the battery for the
pulse coder is connected,switch the NC on.
3. Absolute position communication is
performed, and a request to return to the
reference position is displayed.
4. Move motor more than one revolution by
JOG Feed.
5. Turn off and on the CNC.
6. Absolute position communication is
performed, and a request to return to the
reference position is displayed.
7. Return to the reference position.
These steps were
added for the α and β
pulse coders.
