Servo Motors Beta Series Maintenance manual Page 39

Maintenance manual
3. START-UP PROCEDURE START-UP PROCEDURE B-65235EN/02
- 38 -
• Series 0-C
Press the PARAM key several times, and the servo setting
screen will appear.
If no servo screen appears, set the following paramter as
shown, and switch the NC off and on again.
#7 #6 #5 #4 #3 #2 #1 #0
389 SVS
SVS (#0) = 0 (to display the servo screen)
When the following menu appears on the screen,
move the cursor to the item you want to set and
enter data directly.
Servo set 01000 N0000
X axis Z axis Power Mate-F, G, H, I Power Mate-E
INITIAL SET BITS 00001010 00001011 No.2000 No.1000
Motor ID No. 16 16 No.2020 No.1020
AMR 00000000 00000000 No.2001 No.1001
CMR 2 2 No.1820 No.100
Feed gear 1 1 No.2084 No.1084
(N/M) 100 1 No.2085 No.1085
Direction Set 111 –111 No.2022 No.1022
Volocity Pulse No. 8192 8192 No.2023 No.1023
Position Pulse No. 12500 12500 No.2024 No.1024
Ref. counter 10000 10000 No.1821 No.324
Value SETTING=
Servo setting menu
Parameter of Power
Mate-E, F, G, H, I
Previous page
Next page
