Servo Motors Beta Series Maintenance manual Page 61

Maintenance manual
3.TROUBLESHOOTING AND
RECOVERY PROCEDURES TROUBLESHOOTING AND RECOVERY
B-65235EN/02
- 60 -
3.1
SERVO AMPLIFIER UNIT
3.1.1
LED Indications and Meanings
If alarm condition related to the servo amplifier unit occurs,
the alarm indicator on the amplifier front panel is lit. Check
the description of alarm at servo tuning screen.
Type Description
Over-voltage alarm
(HV)
This alarm occurs if the DC voltage of the main
circuit power supply is abnormally high.
Low DC link voltage
alarm (LVDC)
This alarm occurs if the DC voltage of the voltage
main circuit power supply is abnormally low or the
outer circuit breaker trips.
Over-regenerative
discharge alarm
(DCOH)
This alarm occurs if:
The average regenerative discharge energy is too
high ( too frequent acceleration / deceleration).
Over-heat alarm
(OH)
This alarm occurs if the temperature of amplifier is
abnormally high.
Fan alarm
(FAL)
The fan, built into the servo amplifier unit, has
stopped.
Over-current alarm
(HC)
This alarm occurs if an abnormally over-current
flows in servo amplifier unit.
