4. DESCRIPTION OF PARAMETERS
B–63200EN/03
8
#7
15000
#6 #5
FLT
#4
CLB
#3
BMO
#2
AGA
#1
LGC
#0
LPC
[Data type] Bit
LPC Power control is:
0 : Disabled. (Normal operation)
1 : Enabled.
LGC The in–tube pressure control gain selection of two types is:
0 : Disabled.
1 : Enabled. (Normal operation)
(When this bit is set to 1, parameter No. 15245 is enabled.)
AGA The assist gas is:
0 : Enabled. (Normal operation)
1 : Disabled. (Maintenance)
BMO When the shutter is closed, the function to turn the beam on is:
0 : Disabled. (Normal operation)
1 : Enabled. (Manual operation only, maintenance)
CLB Power calibration is:
0 : Disabled.
1 : Enabled. (Normal operation)
FLT During power control, the filter is:
0 : Disabled.
1 : Enabled. (Normal operation)
#7
15001
#6
LHC
#5 #4
PC8
#3
NGC
#2
PES
#1
G0B
#0
EXA
[Data type] Bit
EXA An assist gas can be selected from:
0 : Three types. (Normal operation)
1 : Seven types.
G0B Beam output by G00 is
0 : Disabled. (Normal operation)
1 : Enabled.
PES In the machine lock or dry run state, the piercing time is:
0 : Executed. (Normal operation)
1 : Not executed.
NGC The integral for gas pressure control is:
0 : Not preset.
1 : Preset.
PC8 The power calibration function of:
0 : Correction by constant power.
1 : Power is raised to eight steps.
LHC The oscillator is:
0 : Not controlled by an external signal. (Normal operation)
1 : Controlled by an external signal.
