Series 16i/160i-LA Parameter manual Page 66

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63200EN/03
60
15623
Angle at which rotation is assumed to be only plane rotation in three–dimensional
conversion
[Data type] Two–word
[Unit of data] 0.001 deg
[Valid data range] 0 to 89999
If, in three–dimensional conversion, the difference between the
inclination of the plane containing three reference points (P1, P2, and P3)
and that of the plane containing three target points (Q1, Q2, and Q3) is
equal to or less than the angle specified in this parameter, the inclination
difference is ignored and the rotation is assumed to be only rotation in the
X–Y plane.
If this parameter is 0, this compensation process is not executed.
15628 Backlash for the fifth–axis program command
[Data type] Word
[Unit of data]
[Valid data range] –9999 to 9999
Backlash is output when the polarity of the travel direction of nozzle arm 2
reverses. That is, backlash is output when the polarity of the fifth–axis
command reverses.
Before changing this parameter, move the tool along the fifth axis in the
reference position return direction and cancel any existing backlash
compensation.
15629 Backlash for the fifth–axis interaction command
[Data type] Word
[Unit of data] Detection unit
[Valid data range] –9999 to 89999
Backlash is output for the fifth axis when the polarity of the travel
direction of the fourth axis reverses. Before changing this parameter,
move the tool along the fourth axis in the reference position return
direction and cancel any existing backlash compensation.
