Series 16i/160i-LA Parameter manual Page 64

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63200EN/03
58
15615 Length of the first arm
15616 Length of the second arm
[Data type] Two–word
[Unit of data]
Increment system Unit IS–A IS–B IS–C
Millimeter machine mm 0.01 0.001 0.0001
Inch machine inch 0.001 0.0001 0.00001
[Valid data range] 0 to 500000 (Millimeter machine)
0 to 196850 (Inch machine)
Specify the length of the first and second arms.
15617 Interaction gear count for the α axis
[Data type] Byte
[Unit of data]
[Valid data range] 0 to 127
Specify the interaction gear count for the α axis. When the gear count falls
outside beyond the specified range, specify a value divided by the greatest
common divisor of the gear counts of this axis and the β axis.
Example When the gear count of the α axis is 300 and the gear count of
the β axis is 200, 300:200 = 3:2. Specify 3 as the α axis gear
count and 2 as the β axis gear count.
15618 Interaction gear count for the β axis
[Data type] Byte
[Unit of data]
[Valid data range] 0 to 127
Specify the interaction gear count for the β axis.
The β–axis interaction calibration amount is calculated from the α–axis
interaction gear count specified in parameter No. 15617 and this setting.
The calculated value is automatically specified for the β axis.
β–axis interaction calibration amount = α–axis travel distance)
PRM.15618
PRM.15617
