4. DESCRIPTION OF PARAMETERS
B–63200EN/03
24
15114 Pre–flow pressure 1
15115 Pre–flow pressure 2
15116 Pre–flow pressure 3
[Data type] Word
[Unit of data] 0.01 MPa or 0.1 kg/cm
2
[Valid data range] 0 to 255
Specify the pre–flow pressure of the assist gas.
15120 Machining flow pressure 1
15121 Machining flow pressure 2
15122 Machining flow pressure 3
[Data type] Word
[Unit of data] 0.01 MPa or 0.1 kg/cm
2
[Valid data range] 0 to 255
Specify the machining flow pressure of the assist gas.
15126 After–flow pressure 1
15127 After–flow pressure 2
15128 After–flow pressure 3
[Data type] Word
[Unit of data] 0.01 MPa or 0.1 kg/cm
2
[Valid data range] 0 to 255
Specify the after–flow pressure of the assist gas.
15132 Maximum assist gas pressure
[Data type] Word
[Unit of data] 0.01 MPa or 0.1 kg/cm
2
[Valid data range] 0 to 255
Specify a gas pressure with which an analog output of 10V is obtained.
15135 Assist gas pressure stabilization time
[Data type] Word
[Unit of data] 10 milliseconds
[Valid data range] 0 to 32767
Specify an assist gas pressure stabilization time.
