4. DESCRIPTION OF PARAMETERS
51
15535 Lower limit on gap
[Data type] Word
[Unit of data] 0.001 mm
[Valid data range] 0 to 32767
Specify the minimum value that can be specified for the gap in tracing
control.
15536 Upper limit on gap
[Data type] Word
[Unit of data] 0.001 mm
[Valid data range] 0 to 32767
Specify the maximum value that can be specified for the gap in tracing
control.
15537 Tracing range over alarm
[Data type] Word
[Unit of data] 0.001 mm
[Valid data range] 0 to 32767
[Standard setting] 1000
When the absolute value of the value obtained by subtracting the reference
displacement from the detected displacement exceeds this setting in
Z–axis tracing control, an alarm is raised.
15538 Mask time of tracing range over alarm
[Data type] Word
[Unit of data] Millisecond
[Valid data range] 0 to 32767
[Standard setting] 1000
When the reference displacement amount is changed, an alarm is
suppressed in the transition state for the specified mask time.
15539 Calibration amount of tracing range over alarm
[Data type] Word
[Unit of data] 0.001 mm
[Valid data range] 0 to 32767
[Standard setting] 0
The calibration amount can be added to the detected value of the
approaching side to give the setting of parameter No. 15537.
