Series 16i/160i-LA Parameter manual Page 52

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63200EN/03
46
15500 Detection gain coefficient
[Data type] Word
[Unit of data]
[Valid data range] 0 to 65536
Specify the gain coefficient of the displacement detector in Z–axis tracing
control.
NOTE
This parameter can be set on the trace setting screen.
15502 Detection zero point
[Data type] Word
[Unit of data]
[Valid data range] –32768 to 32767
The zero point calibration value is used to calibrate the zero point of the
displacement detector in Z–axis tracing control.
NOTE
This parameter can be set on the trace setting screen.
15503 Filter time constant
[Data type] Word
[Unit of data] Millisecond
[Valid data range] 0 to 32767 (Must not set to 1)
[Standard setting] 0
The setting is the time constant of a filter for eliminating the disturbance
component from the displacement in Z–axis tracing control.
15504 Displacement multiplier
[Data type] Word
[Unit of data]
[Valid data range] 1 to 5
[Standard setting] 1
Specify a multiply ratio for supporting a large detection amount in Z–axis
tracing control.
Setting Maximum displacement (mm) Resolution (mm)
1 "2 0.001
2 "4 0.002
3 "6 0.003
4 "8 0.004
5 "10 0.005
4.18
SETTINGS RELATED
TO TRACING
(DETECTION)
