4. DESCRIPTION OF PARAMETERS
39
15280 Power table interval when half of the discharge tubes are used
15281 Power table interval when all of the discharge tubes are used
[Data type] Word
[Unit of data]
[Valid data range] 0 to 32767
[Standard setting] Refer to the appended parameter sheet.
Specify a power setting interval, in Watts.
15290 Value 0 when half of the discharge tubes are used
15291 Value 1 when half of the discharge tubes are used
15292 Value 2 when half of the discharge tubes are used
15293 Value 3 when half of the discharge tubes are used
15294 Value 4 when half of the discharge tubes are used
15295 Value 5 when half of the discharge tubes are used
15296 Value 6 when half of the discharge tubes are used
15297 Value 7 when half of the discharge tubes are used
15298 Value 8 when half of the discharge tubes are used
[Data type] Word
[Unit of data] W
[Valid data range] 0 to 32767
[Standard setting] Refer to the appended parameter sheet.
Specify power settings 0 to 8 at the table intervals, in the indicated order,
when half of the discharge tubes are used.
