Series 16i/160i-LA Parameter manual Page 90

Parameter manual
5. DESCRIPTION OF PARAMETERS
(YP SERIES)
B–63200EN/03
84
15200 Power specified for power calibration
[Data type] Word
[Unit of data] W
[Valid data range] 0 to 32767
Specify the power to be specified to obtain a power calibration coefficient.
15203 Power calibration limit
[Data type] Word
[Unit of data]
[Valid data range] 0 to 32767
[Standard setting] 1200
When the power calibration coefficient exceeds this setting, the MWRN
signal is output to indicate that the mirror should be cleaned or replaced.
15204 Power calibration coefficient
[Data type] Word
[Unit of data]
[Valid data range] 0 to 32767
[Standard setting] Automatic setting
The coefficient is used to calibrate the specified power according to the
actual power.
This parameter is automatically set during power calibration after a RUN
start.
15205 Power calibration time
[Data type] Word
[Unit of data] sec
[Valid data range] 0 to 32767
[Standard setting] 180
Specify a power calibration time.
15207 Current value for power calibration
[Data type] Word
[Unit of data] A
[Valid data range] 0 to 1000
Set the current value during power calibration.
5.4
PARAMETERS
RELATED TO
OSCILLATOR
CONTROL
