Series 16i/160i-LA Parameter manual Page 37

Parameter manual
B–63200EN/03
4. DESCRIPTION OF PARAMETERS
31
15217 Beam stop delay time
[Data type] Word
[Unit of data] Millisecond
[Valid data range] 0 to 32767
Specify the period from when an in–position check is completed until the
beam stops.
15218 Power for clamping the duty ratio of the CW–YAG laser
[Data type] Word
[Unit of data] W
[Valid data range] 0 to 32767
When laser power Pc, specified for the CW–YAG laser, exceeds this setting,
the upper limit of the duty ratio is clamped to:
No.15218
Pc
100(%) When
0 is specified, 500 W is assumed.
15219 Beam output condition delay time
[Data type] Byte
[Unit of data] 8 milliseconds
[Valid data range] 0 to 8
Specify the delay time from the point the CNC specifies beam output
conditions until the output conditions for the beam to be output from the
oscillator are actually changed.
