B-70265EN/02 5.TROUBLESHOOTING

- 85 -

Alarm output condition

Turning the oscillator start switch on causes exhaust to start. This alarm

is issued if the laser gas pressure does not reach the setting of

parameter No. 15240 when the time set in parameter No.15259 has

elapsed.

Related parameters

PRM.15240 Evacuation completion negative pressure

PRM.15259 RUN-ON exhaust time

Related data

DGN.905 Actual gas pressure

No. Cause of trouble Solution

1 Incorrect gas pressure

control parameter setting

Check if the value of PRM No. 15240 is set as

indicated in the attached parameter table. If a

different value is set, set the value specified

in the data sheets.

2 Anomaly of IF PCB

(A16B-2100-0142)

If the gas pressure of the gas circulating

system does not decrease at all, the IF PCB

may be faulty. Check whether the

CP89(Solenoid valve signal) connector on

the PCB is loose. Also check the signals of

the IF PCB. If an abnormal signal is detected,

replace the IF PCB.

3 Gas leakage from piping 1) Check whether any component joints in the

gas circulating system are loose. If a loose

joint is found, tighten the joint firmly.

2)Check whether any components in the gas

circulating system are cracked. If a cracked

component is found, replace that

component.

3)Check whether the O-ring of each

discharge tube is worn. Replace any O-

rings that exhibit excessive wear. If a

Teflon O-ring is ever removed, it must be

replaced with a new one.

4)Check whether there is a hole or crack in a

discharge tube. If a hole is found in a

discharge tube, replace the discharge tube.

4 Anomaly of exhaust pump Check whether the piping between the

oscillator and exhaust pump is normal.

(C1000-E only)
