Laser C1000/C2000/C4000/C5000/C6000-Model E Maintenance manual Page 88

Maintenance manual
4.MAINTENANCE B-70265EN/02
- 68 -
Maintenance parts [Repairable parts]
Q’ty
Name Specification
C1000-E C2000-E C4000-E C5000-E C6000-E
1
Laser power supply
unit
A14B-0082-B211 1 2 4 4 6
2 A14B-0082-B316 1 0 0 0 0
3 A14B-0082-B311 0 2 0 0 0
4 A14B-0082-B315 0 0 4 0 0
5 A14B-0082-B320 0 0 0 4 0
6 A14B-0082-B318 0 0 0 0 4
7
Matching box
A14B-0082-B319 0 0 0 0 2
8
IF PCB (for 16i-L)
A16B-2100-0142 1 1 1 1 1
9
IF PCB
(for expansion)
A16B-1600-0780 0 0 0 0 1
10 Gas control PCB A16B-1700-0490 1 0 0 1 1
11 Intermediate PCB B A16B-1600-0361 1 1 1 1 1
12 A16B-1600-0660 1 0 0 0 0
13 A16B-1600-0661 0 1 1 1 0
14
Input unit control PCB
A16B-1600-0663 0 0 0 0 1
15 Turbo PCB A16B-1600-0670 1 1 1 1 1
16
Stabilized power
supply
A20B-1005-0124 1 1 1 1 1
17 A91L-0001-0225 1 0 0 0 0
18 A04B-0807-D001 0 1 1 1 0
19
Power sensor unit
A04B-0809-D001 0 0 0 0 1
20 A04B-0816-D410 1 0 0 0 0
21 A04B-0810-C410 0 1 0 0 0
22 A04B-0815-C410 0 0 1 0 0
23 A04B-0817-D410 0 0 0 1 0
24
Shutter unit
A04B-0818-D410 0 0 0 0 1
25 A04B-0800-C013 1 0 0 0 0
26 A04B-0800-C011 0 1 0 0 0
27
Turbo blower
A04B-0800-C015 0 0 1 2 2
28 A90L-0001-0500#8LF 1 1 1 0 0
29
Inverter
A90L-0001-0500#16LF 0 0 0 1 1
30
Charge unit (for gas
controller)
A04B-0816-D400 1 0 0 1
1
31 A04B-0816-D401 1 0 0 0 0
32 A04B-0817-D400 0 0 0 1 0
33
Exhaust unit (for gas
controller)
A04B-0818-D400 0 0 0 0 1
34
Sensor base (for gas
controller)
A290-4514-V040 1 0 0 1 1
35 Pressure control unit A04B-0811-C400 0 1 1 0 0
36 A91L-0001-0217#0-T2 1 0 0 0 1
37 A91L-0001-0217#0-T3 0 0 0 1 0
38
A91L-0001-0201+
A660-8013-T620#L500R0
(1) 0 0 0 (1)
39
Pressure sensor
A91L-0001-0201 0 1 1 0 0
40 A04B-0816-D402 1 0 0 1 1
41
Control valve
A97L-0200-0797#B 0 1 1 0 0
42
Water distributor unit
(out)
A290-4514-V801 1 0 0 0 0
43
Water distributor unit
(in)
A04B-0816-C421 1 0 0 0 0
