3.INSTALLATION B-70265EN/02

- 52 -

CAUTION

1 First, check the beam position. Laser light, if

allowed to penetrate the acrylic material because of

incorrect operation, is very dangerous. The paint of

the machine is also likely to be damaged. So,

attach as feel plate, then an acrylic plate, about

30cm × 30cm × 3mm in size.

If a guide laser is used, confirm that CO

gas laser

light is directed to the same spot as the guide laser.

2 Ventilate the optical path. Acrylic gas staying

around the optical path can increase the mode

diameter or cause shape deformation, which

prevents correct mode checking.

(4) Next, attach an acrylic block (with a thickness of 30 mm or

more) to the position indicated by the white acrylic mark. Ensure

that the surface of the acrylic block is perpendicular to the

direction of CO

gas laser light. The perpendicularity of the

acrylic block surface can be checked by adjusting the block such

that the guide laser is reflected from the acrylic block surface

and returns to the beam outlet.

(5) Set the conditions of the beam output program as follows:

Output = Rated output

Duty = 100 %

Duration = See the following table.

Perform internal discharge with a rated output specified. If actual

output Pa differs from the specified output, mode shape

comparison becomes difficult. So, modify the command so that

the output difference is suppressed to within ±2%.

Example

With the C4000-E, setting is made to output 4080 W to

3920 W.

Model Duration

C1000-E 4 seconds

C2000-E 4 seconds

C4000-E 2.5 seconds

C5000-E 1.5 seconds

C6000-E 2.5 seconds

(6) Direct the drier so that it blows air at 45° to the acrylic block,

then output the beam. If air is not provided correctly, the acrylic

vapor will catch fire. If fire occurs, the mode depth may become

shortened.

The following two types of mode patterns are collected:

Cold mode:

A pattern is obtained after the oscillator is left in the base

discharge state for at least five minutes to let the resonator

cool down.
