3.INSTALLATION B-70265EN/02

- 54 -

3.4 PREPARATION PRIOR TO SHIPMENT

For shipment and transportation, follow the steps explained below.

(1) Disconnect all CNC connecting cables.

(2) Disconnect the power cable and ground cable. Cover the cable

inlet holes with tape or the like.

(3) Remove the laser gas pipes, and attach blanking plugs to the

pipes to prevent dust from entering.

(4) Detach the cooling water piping, and remove the water. For

details of how to remove the cooling water, see Subsection 3.4.2.

CAUTION

Any residual cooling water may result in corrosion

or clogging; furthermore, if any residual cooling

water freezes, a pipe or the oscillator itself may be

damaged.

(5) Install the resonator clamp and shutter clamp, and fit a blanking

cap onto the beam outlet.

(6) Check the security of all connectors and printed circuit boards.

Install protective covers.

(7) Check that all removed mounting screws are reinstalled.

(8) Install the cabinet mounting panel.

3.4.1 Packing for Transportation

Prior to shipment and transportation, the packing and checking

operations described below must be performed.

(1) External dimensions : See the Appendix A.

(2) Weight of product :

Model Weight

C1000-E Approx. 350kg + Approx. 30kg (pump)

C2000-E Approx. 700kg

C4000-E Approx. 900kg

C5000-E Approx. 1,100kg

C6000-E Approx. 1,300kg

(3) Maximum allowable impact : 2G

Note that the maximum allowable impact in transit depends

greatly on the means of transport employed, as indicated in

Table 3.4.1.

Table 3.4.1 Maximum allowable impacts according to means of

transport (Units: G)

Means of transport

Airplane Ship Railroad Truck

Forwards/

backwards

615125

Left/right

2.5 12 5 4

Direction

Up/down

2.5 12 5 4
