Laser C1000/C2000/C4000/C5000/C6000-Model E Maintenance manual Page 165

Maintenance manual
B-70265EN/02 7.UNITS
- 145 -
Name Description
Operation key Key for stopping the motor.
This key, however, is enabled only when the
operation command destination is set to the
operator. (Check that the operation command
indication lamp is on.)
STOP/RESET key Used to stop the motor or reset an alarm.
FUNC (function) key Used to enter the monitor mode, basic setting
mode, extended function mode, and function
mode.
STR (store) key Used to store set values. (Be sure to press this
key when changing set values.)
Up/down key Used to change the extended function mode,
function mode, or set values.
Previous page
Next page
