Laser C1000/C2000/C4000/C5000/C6000-Model E Maintenance manual Page 291

Maintenance manual
B-70265EN/02 APPENDIX E.PARAMTER LIST
- 271 -
15056 Type of piercing assist gas
[Data type] Word
[Unit of data]
[Valid data range] 0 to 7
Set a type of assist gas to be used for piercing.
15057 Return distance
[Data type] 2-word
[Unit of data]
Increment system IS-A IS-B IS-C Unit
Metric input 0.01 0.001 0.0001 mm
Inch input 0.001 0.0001 0.00001 inch
[Valid data range] 0 to 65000
Set a return distance from the top of a corner to the next block.
15058 Return feedrate
[Data type] Word
[Unit of data] mm/min
[Valid data range] 0 to 9999
Set a return feedrate to be used for movement from the top of a corner
to the next block.
15059 Peak return power value
[Data type] Word
[Unit of data] W
[Valid data range] 0 to 7000
Set a peak return power value to be used for movement from the top
of a corner to the next block.
15060 Return frequency
[Data type] Word
[Unit of data] Hz
[Valid data range] 5 to 2000
Set a return frequency to be used for movement from the top of a
corner to the next block.
15061 Return duty ratio
[Data type] Word
[Unit of data] %
[Valid data range] 0 to 100
Set a return duty ratio to be applied to movement from the top of a
corner to the next block.
