  2. 16i/18i/21i-B maintenance manual for SD7

16i/18i/21i-B maintenance manual for SD7 Maintenance manual Page 632

Maintenance manual
H Absolute position
H Relative position
H Machine position
H Remaining travel amount
H Actual speed
D NC program
D Part program storage directory information
D NC data file
H Parameter
H Tool offset value
H Custom macro variable
H Workpiece origin offset
H Setting data
H P code macro variable
H Pitch error compensation
D Tool life management data
D History data
H Operation history data
H Alarm history data
D Servo–/spindle–related data
D Data related to waveform diagnosis
D Modal data
D Diagnosis data
D A/D conversion data
D Alarm information
D NC system identification information
D PMC data
H Addresses G, F, Y, X, A, R, T, K, C, D
H Extended nonvolatile data
From the personal computer, the following operations can be performed:
D NC program selection
D NC program deletion
D External reset
NOTE
With the FOCAS1/Ethernet function of the embedded
Ethernet function, DNC operation cannot be performed.
Remote operation
8. EMBEDDED ETHERNET FUNCTION
GFKE-0222-EN
602
Previous page
Next page

Contents Summary of 16i/18i/21i-B maintenance manual for SD7 Maintenance manual
