POWER MATE 0 Maintenance manual Page 102

Maintenance manual
B–63445EN/01
4.INTERFACE BETWEEN NC AND PMC
87
Type Byte Address Explanation
G PMC⇒CNC 256 G000.0 to G255.7
F CNC⇒PMC 256 F000.0 to F255.7
Y PMC⇒MT 3 Y1000.0 to Y1002.7 Built–in I/O card
X MT⇒PMC 4 X1000.0 to X1003.7 Built–in I/O card
A Massege display 25 A000.0 to A024.7
R Internal relay 1100 R000.0 to R999.7
R9000.0 to R9117.7 Operation result, system re-
serve area
T Variable timer 80 T000.0 to T079.7
K Keep relay 20 K000.0 to K016.7
K017.0 to K019.7 System reserve area
C Counter 80 C000.0 to C079.7
D Data table 1860 D0000.0 to D1859.7
Function Contents
Display of sequence pro-
gram
Dynamic display of ladder diagram
* This function is not provided by the DPL/MDI.
Diagnostic function S Title data display
S Signal status
S PMC alarm display
Setting and displaying data S Timer
S Counter
S Keep relay
S Data table
Sequence program edit
function
S For CRT/MDI
Ladder diagram editing
(A ladder edit module for memory card is re-
quired)
S For DPL/MDI
S Use the FAPT LADDER.
4.2.2
Address
4.2.3
Built–in Debug
Function
