POWER MATE 0 Maintenance manual Page 98

Maintenance manual
B–63445EN/01
3. INPUT AND OUTPUT OF DATA
83
1. Make sure the input device is ready for reading.
2. Set to the emergency stop state.
3. Press
OFFSET
SETTING
key.
4. Press the soft key
[SETING] for chapter selection.
5. Enter 1 in response to the prompt for writing parameters (PWE).
Alarm P/S100 (indicating that parameters can be written) appears.
6. Press
SYSTEM
key.
7. Press the rightmost soft key
(next–menu key)and press chapter
selection soft key
[PITCH].
8. Press soft key [(OPRT)].
9. Press the rightmost soft key
(next–menu key).
10.Press soft keys
[READ] and [EXEC].
Parameters are read into memory. Upon completion of input, the
“INPUT” indicator at the lower–right corner of the screen disappears.
11.Press
OFFSET
SETTING
key.
12.Press soft key
[SETING] for chapter selection.
13.Enter 0 in response to the prompt for writing parameters.
14.Turn the power to the NC back on.
15.Release the emergency stop state.
1. Select the EDIT (editing) mode.
2. Press the
key to display the pitch error compensation data screen.
3. Perform the same operation as for program input.
4. By performing this operation, pitch error compensation value is read
into memory.
3.2.15
Inputting Pitch Error
Compensation Value
Procedure (CRT/MDI)
Procedure (DPL/MDI)
