POWER MATE 0 Maintenance manual Page 129

Maintenance manual
4. INTERFACE BETWEEN NC AND PMC
B–63445EN/01
114
Symbol Signal name PMC address
:
ABSM Manual absolute signal G006#2
AFL Auxiliary function lock signal G005#6
AL CNC alarm signal F001#0
BAL Battery alarm signal F001#2
BDT Optional block skip signal G044#0
BDTO Optional block skip signal (software operator’s panel) F075#2
BGEACT Background editing signal F053#4
CSS Constant speed signal F002#2
CUT Signal under cutting F002#6
:
DEC1,
:
DEC2 Reference position return deceleration signal X000#5, X001#5
DEN Distribution end signal F001#3
DNCI DNC operation signal G043#5
DPL0 to DPL2 Screen status signal F254#0 to #2
DRN Dry run signal G046#7
DRNO Dry run signal (software operator’s panel) F075#5
ENB Spindle enable signal F001#4
ERS External reset signal G008#7
:
ESP Emergency stop signal G008#4, X000#4
FIN End signal G004#3
:
FLWU Follow–up signal G007#5
:
FV0 to
:
FV7
Feedrate override signal G012
:
FV0O to
:
FV7O
Feedrate override signal (software operator’s panel) F078
GR1, GR2 Gear selection signal G028#1, #2
HS1A, HS1B Manual handle feed axis select signal G018#0, #1
HS1AO, HS1BO Manual handle feed axis select signal (software operator’s panel) F077#0, #1
IGNVRY Speed control servo alarm ignored signal G066#0
INP1, INP2 In–position signal F104#0, #1
:
IT Interlock signal G008#0
:
IT1,
:
IT2 Each axis interlock signal G130#0, #1
4.7
SIGNAL AND
SYMBOL
CORRESPONDENCE
TABLE
