POWER MATE 0 Maintenance manual Page 234

Maintenance manual
B-63444EN/01-1
3/3
EDIT
DATE DESIG. DESCRIPTION
FANUC Power Mate 0
THE FUNCTION OF
ABSOLUTE PULSE CODER
TITLE
DRAW.NO.
CUST.
SHEET
01
000512 New design
shown below.
#7 #6 #5 #4 #3 #2 #1 #0
202 CSA BLA PHA RCA BZA CKA SPH
CSA : The serial pulse coder is defective. Replace the serial pulse
coder.
BLA : The battery voltage is low. Replace the batteries.
PHA : The serial pulse coder or feed back cable is defective.
Replace the serial pulse coder or cable.
RCA : The serial pulse coder is defective. Replace it.
BZA : The pulse coder was supplied with power for the first time.
Make sure that the batteries are connected.
Turn the power off, then turn it on again and perform a
reference position return.
CKA : The serial pulse coder is defective. Replace it.
PHA
:
The serial pulse coder or feedback cable is defective.
Replace the serial pulse coder or cable.
